Free guide

12 Tips for Better Design Control

12 tips to apply in your design and development process for medical devices, from your D&D plan to design freeze. Read them all below or download the PDF, no form required.

Last updated

This is the full text of our design control guide, free to read here with no form to fill in. Prefer a copy for your team? Download the PDF (1 page).

Design control is at the heart of medical device development. Whether you're building a Class II device or a complex SxMD system, these 12 tips will help you establish a robust, audit-ready design control process that keeps your team aligned and your documentation complete.

1. Start with a clear D&D Plan

Use a simple, flexible plan document from the beginning to define stages, responsibilities, and update it iteratively. A well-structured Design and Development plan sets the foundation for your entire project, ensuring everyone on the team understands the scope, timeline, and deliverables from day one.

2. Map requirements to user needs

For every user need, create traceable design inputs. Use a traceability matrix to link needs to inputs, inputs to outputs, and outputs to tests. This ensures nothing falls through the cracks and every design decision can be traced back to a real user need.

3. Differentiate Inputs from Outputs

Design inputs describe what the product must do; outputs show how the product achieves those goals. Keep them distinct. Confusing inputs and outputs is one of the most common mistakes in design control and can lead to gaps in your verification and validation strategy.

4. Use unique identifiers

Assign unique codes or IDs to each requirement, test, spec, and document to ensure traceability across systems. Unique identifiers make it possible to quickly locate any item in your design history file and understand its relationships to other design elements.

5. Use a living traceability matrix

Keep a centralized, version-controlled traceability matrix updated continuously from concept to validation. A living matrix that evolves with your project is far more valuable than a static document created at the end — it helps you catch gaps early and stay audit-ready at all times.

6. Avoid jumping to solutions

Record design inputs as performance needs (e.g., "needs 15 lumens of light") not pre-defined solutions ("use 8V battery"). Framing requirements as problems to solve rather than solutions to implement gives your engineering team the freedom to find the best approach.

7. Document iterations explicitly

When a verification or validation fails, log changes and clearly mark the new input/output versions linked to the tests. Every iteration should be traceable so you can demonstrate to auditors that your design evolved through a controlled, documented process.

8. Integrate risk management

Link each input/output to corresponding risks (when possible) and risk control measures under ISO 14971. Update both together when changes occur. Risk management should not be a separate silo — it needs to be woven into your design control process from the start.

9. Version control everything

Track versions of every document. Never overwrite; archive old versions with comments on changes and reason. Version control is not just good practice — it's a regulatory requirement. Being able to show the complete history of any document is essential for audits.

10. Design freeze with rationale

When freezing a design, log rationale, approved drawings, and testing implications. Freeze only when V&V can proceed safely. A design freeze without proper documentation can create confusion later about what exactly was verified and validated.

Each test in the verification protocol must clearly trace back to the design input it is proving. This bidirectional traceability ensures complete coverage and makes it easy to demonstrate during audits that every requirement has been verified.

12. Train team on traceability concepts

Ensure every team member understands document types, traceability importance, and their role in maintaining it. Traceability is only as strong as the team's commitment to it — from user needs through requirements, design items, verification tests, risk assessments, and clinical evidence.

Use an ALM in your design control

Matrix Req connects, traces and controls everything in one place: user needs, requirements, design items, verification tests, risks and clinical evidence.
